Shandong Luhongda Machinery Co., Ltd.
Product Details
Place of Origin: Shandong, China
Brand Name: LUHONGDA
Model Number: 16 ton road roller
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Type: |
Tire Roller |
Travel Speed: |
0-14km/h |
Grade Ability: |
30% |
Make: |
LUHONGDA |
Power(W): |
74 KW |
Dimension(L*W*H): |
4780*2280*3200mm |
Warranty: |
1 Year |
Hydraulic Pump Brand: |
Top Brand |
Hydraulic Valve Brand: |
Top Brand |
Engine Brand: |
Cummins |
UNIQUE SELLING POINT: |
EPA Engine |
Drum Diameter: |
1050MM |
Drum: |
Double Drum Roller |
Exciting Force: |
80 KN |
Machinery Test Report: |
Provided |
Video Outgoing-inspection: |
Provided |
Core Components: |
Motor, Pump, Engine |
Engine Model: |
Cummins Engine QSB3.9 |
Engine Type: |
Water-cooled |
Compaction Width: |
2280mm |
Minimum Turning Radius: |
7500mm |
Wheelbase: |
3700mm |
Track Width: |
500mm |
Fuel Tank Capacity: |
180 L |
Water Tank Capacity: |
1000 L |
Steering Wheel Type: |
Dual-Side Steering |
Maximum Gradeability: |
0.3 |
Type: |
Tire Roller |
Travel Speed: |
0-14km/h |
Grade Ability: |
30% |
Make: |
LUHONGDA |
Power(W): |
74 KW |
Dimension(L*W*H): |
4780*2280*3200mm |
Warranty: |
1 Year |
Hydraulic Pump Brand: |
Top Brand |
Hydraulic Valve Brand: |
Top Brand |
Engine Brand: |
Cummins |
UNIQUE SELLING POINT: |
EPA Engine |
Drum Diameter: |
1050MM |
Drum: |
Double Drum Roller |
Exciting Force: |
80 KN |
Machinery Test Report: |
Provided |
Video Outgoing-inspection: |
Provided |
Core Components: |
Motor, Pump, Engine |
Engine Model: |
Cummins Engine QSB3.9 |
Engine Type: |
Water-cooled |
Compaction Width: |
2280mm |
Minimum Turning Radius: |
7500mm |
Wheelbase: |
3700mm |
Track Width: |
500mm |
Fuel Tank Capacity: |
180 L |
Water Tank Capacity: |
1000 L |
Steering Wheel Type: |
Dual-Side Steering |
Maximum Gradeability: |
0.3 |
ITMIRS | SPECIFICATION |
Minimum Operating Weight | 10 ton |
Maximum Operating Weight | 16 ton |
Tire Size | 11.00-20-16 |
Tire Configuration (Front/Rear) | Front 4 / Rear 5 |
Front Wheel Diameter × Width | 1050×285mm |
Rear Wheel Diameter × Width | 1050×285mm |
Tire Suspension Type | Front Wheel Oscillation / Rear Wheel Rigid Suspension |
Front Wheel Vertical Travel | 200mm |
Transmission Type | Hydrostatic Transmission |
Drive Mode | Rear-Wheel Drive |
Front/Rear Wheel Overlap Width | 50mm |
Compaction Width | 2280mm |
Minimum Turning Radius | 7500mm |
Minimum Ground Clearance | 300mm |
Maximum Gradeability | 0.3 |
Rated Power | 74 kW |
Rated Speed | 2300 rpm |
Diesel Engine Model | Cummins Engine QSB3.9 |
Engine Cooling Method | Water-Cooled |
Maximum Forward Speed | 0-14 km/h |
Wheelbase | 3700mm |
Track Width | 500mm |
Fuel Tank Capacity | 180 L |
Water Tank Capacity | 1000 L |
Dimensions (L×W×H) | 4780×2280×3200mm |
Steering Wheel Type | Dual-Side Steering |
Seat Type | Adjustable |
Frame Type | Integral Structure |
Water Spray System Type | Electronically Controlled Water Spray |
